CAD drawing credits

背景の線画は、登録済みCADのメッシュを正投影し、隠線処理して出力しています。形状の描き起こしや生成補完は行っていません。透明パネルを非表示にし、部品図では指定したアセンブリだけを表示しています。

The background contains orthographic, hidden-line renders of the actual catalog meshes. Transparent panels are hidden. The toolhead and gantry drawings isolate their original assembly groups. Geometry and relative part placements are preserved; drawings use individual camera scales.

• VORON V0.2r1 / 120 — VoronDesign. Original CAD and credits · GPL-3.0.
• VORON V2.4 / 300, original toolhead and XY gantry — VoronDesign. Original CAD and credits · GPL-3.0. The catalog adapts the original 250 mm assembly to 300 mm. The installed Stealthburner / CW2 / Revo assembly also uses VoronDesign/Voron-Stealthburner (GPL-3.0).
• VORON Trident / 300 — VoronDesign. Original CAD and credits · GPL-3.0.
• Micron Plus R1 / 180 — PrintersForAnts and the component designers credited in the original assembly. Original CAD and credits · GPL-3.0.

Derived drawings retain GPL-3.0 and the original component credits. These decorative source-pose drawings are not manufacturing drawings or clearance validation.

Drawing manifest, hashes and assembly selections · Exact input mesh bundle · Reproduction scripts
